Overview
◆Material： NYLON with metal powder, UL94-HB.
◆Application temperature：-40℃ to 85℃
◆Installation temperature：-10℃ to 85℃
◆Color： Blue
◆Feature： Apply for Food and Medical industrial, can be detected by
Metal sensor.
Technical Parameters
| 编 号 Item NO. | L(长) | W(宽) (mm) | (最大)捆扎范围 Max.Bundle DIA.(mm) | 最小拉力 Tensile Strength | ||
| Inch | mm | LBS | KGS | |||
| CHS-3×100MD | 4″ | 100 | 2.5 | 22 | 18 | 8 |
| CHS-4×150MD | 6″ | 150 | 3.6 | 35 | 40 | 18 |
| CHS-4×200MD | 8″ | 200 | 3.6 | 53 | 40 | 18 |
| CHS-5×200MD | 8″ | 200 | 4.8 | 53 | 50 | 22 |
| CHS-5×250MD | 10” | 250 | 4.8 | 65 | 50 | 22 |
| CHS-5×300MD | 11 5/8" | 300 | 4.8 | 82 | 50 | 22 |
| CHS-5×380MD | 15" | 380 | 4.8 | 105 | 50 | 22 |
| CHS-8×300MD | 11 5/8" | 300 | 7.6 | 80 | 120 | 55 |
| CHS-8×350MD | 13 3/4" | 350 | 7.6 | 90 | 120 | 55 |
| CHS-8×400MD | 15 3/4" | 400 | 7.6 | 105 | 120 | 55 |
| CHS-8×500MD | 19 11/16" | 500 | 7.6 | 145 | 120 | 55 |
