L-type naked Stainless Steel Cable Ties



Overview

◆Characteristic：They have an unique ball locking with plastic jetting mechanism that allow easily and quickly installed and notundone;
◆High tensile strength：Non-flammability;
◆Temperature：Working temperature -60℃ to 550℃;
◆High resistance to acetic acid ,alkali acid,sulphuric acid,corrode etc;
◆All length are available,stainless steel type：304,316.

Technical Parameters

编号 Item NO.	长度		宽度 (mm)	厚度 (mm)	（最大）捆扎范围 Max.bundle Dia.(mm)	最小拉力 Tensile Strength
编号 Item NO.	INCH	MM	宽度 (mm)	厚度 (mm)	（最大）捆扎范围 Max.bundle Dia.(mm)	LBS	KGS
LTN-12×200	8″	200	12	0.3	50	270	120
LTN-12×250	10″	250	12	0.3	63	270	120
LTN-12×300	11 5/8″	300	12	0.3	76	270	120
LTN-12×350	13 3/4″	350	12	0.3	89	270	120
LTN-12×400	15 3/4″	350	12	0.3	102	270	120
LTN-12×450	17 3/4″	450	12	0.3	115	270	120
LTN-12×500	19 11/16″	500	12	0.3	128	270	120
LTN-12×550	21 1/16″	550	12	0.3	141	270	120
LTN-15×250	10″	250	15	0.3	63	337	150
LTN-15×300	11 5/8″	300	15	0.3	76	337	150
LTN-15×350	13 3/4″	350	15	0.3	89	337	150
LTN-15×400	15 3/4″	400	15	0.3	102	337	150
LTN-15×450	17 3/4″	450	15	0.3	115	337	150
LTN-15×500	19 11/16″	500	15	0.3	128	337	150
LTN-15×600	23 5/8″	600	15	0.3	154	337	150
LTN-15×700	27 1/2″	700	15	0.3	180	337	150
LTN-15×750	29 9/16″	750	15	0.3	191	337	150
LTN-15×800	32″	800	15	0.3	193	337	150
LTN-15×1000	39 3/8″	1000	15	0.3	206	337	150
LTN-19×300	11 5/8″	300	19	0.4	76	440	200
LTN-19×400	15 3/4″	400	19	0.4	102	440	200
LTN-19×500	19 11/16″	500	19	0.4	141	440	200
LTN-19×600	23 5/8″	600	19	0.4	154	440	200
LTN-19×700	27 1/2″	700	19	0.4	180	440	200
LTN-19×800	32″	800	19	0.4	193	440	200
LTN-19×900	36 1/4″	900	19	0.4	200	440	200
LTN-19×1000	39 3/8″	1000	19	0.4	206	440	200
