Overview
◆ Material：Nylon 66, 94V-2 certificated by UL. Acid & erosion control, insulate well and not easy to aging、tensile strong.
◆ Application temperature：-40℃ to 85℃.
◆ Installation temperature：-20℃ to 85℃.
◆ Color：Natural,Black,UV black, other colors are available as requested.
◆ Feature：Double-sided tooth design,the tension is 20% stronger than
ordinary cable ties.
Technical Parameters
| 编 号 Item NO. | L(长) (mm) | W(宽) (mm) | 最大捆扎范围 Max.Bundle Dia. E (mm) | 拉 力 Min.loop Tensile Strength | |
| LBS | KGS | ||||
| DTS-4X150 | 150 | 3.6 | 35 | 50 | 22 |
| DTS-4X200 | 200 | 3.6 | 50 | 50 | 22 |
| DTS-4X250 | 250 | 3.6 | 65 | 50 | 22 |
| DTS-4X300 | 300 | 3.6 | 80 | 50 | 22 |
| DTS-5X180 | 180 | 4.8 | 42 | 60 | 27 |
| DTS-5X200 | 200 | 4.8 | 50 | 60 | 27 |
| DTS-5X250 | 250 | 4.8 | 65 | 60 | 27 |
| DTS-5X280 | 280 | 4.8 | 70 | 60 | 27 |
| DTS-5X300 | 300 | 4.8 | 82 | 60 | 27 |
| DTS-5X350 | 350 | 4.8 | 90 | 60 | 27 |
| DTS-5X400 | 400 | 4.8 | 108 | 60 | 27 |
| DTS-5X450 | 450 | 4.8 | 130 | 60 | 27 |
| DTS-5X500 | 500 | 4.8 | 150 | 60 | 27 |
| DTS-8X200 | 200 | 7.6 | 50 | 145 | 65 |
| DTS-8X300 | 300 | 7.6 | 90 | 145 | 65 |
| DTS-8X400 | 400 | 7.6 | 105 | 145 | 55 |
| DTS-8X450 | 450 | 7.6 | 125 | 145 | 55 |
| DTS-8X500 | 500 | 7.6 | 145 | 145 | 55 |
| DTS-9X600 | 600 | 9.0 | 170 | 210 | 95 |
| DTS-9X700 | 700 | 9.0 | 205 | 210 | 95 |
| DTS-9X920 | 920 | 9.0 | 265 | 210 | 95 |
| DTS-9X1020 | 1020 | 9.0 | 295 | 210 | 95 |
